Model Information
|
|
Grade:Top Grade
|
Brand: TENETH
|
Market time: 2012-7
|
Warranty: 1 year
|
|
Model Number: TENETH cutting plotter T-48L
|
|
Basic Parameter
|
|
Material
|
Sheet metal +aluminum alloy
|
Media way
|
Floor stand
|
|
Max.Paper feed width
|
1310MM
|
Max.Cutting Size
|
1205MM
|
|
Paper feeding system
|
Drum steel thorn paper
|
Paper feeding way
|
Dual paper stick flat manually
|
|
Axis steel distribution
|
Universal size distribution
|
Number of Axis steel
|
7pcs
|
|
Platen device
|
Double springs huge pressure roller holder
|
Number of Roller holder
|
4 units
|
|
Driver
|
Micro-step driver
|
Origin setting
|
Set each original points manually
|
|
Cutting Speed
|
50-800MM/S
|
Cutting length
|
Unlimited
|
|
Cutting Precision
|
0.005MM
|
Repeatable
precision
|
<0.005MM
|
|
Cutting force
|
5-500g
|
Cutting thickness
|
0.05MM-1MM
|
|
Idling Speed
|
0-3 gear adjustable
|
Noise
|
60-65dB
|
|
Control System
|
|
Mainboard
|
32-bit ARM7 CPU,4MB
|
Control Panel
|
11 silicon buttons + LCD touch screen
|
|
transmission mode
|
Serial Port+USB+U disk
|
Repeat Function
|
Offline a key re-engraved to start
|
|
Repeat Function
|
1 - 500pcs
|
Memory Function
|
Power off doesn't remove source files
|
|
Memory Capacity
|
4M
|
Transmission speed
|
38.4K/56K
|
|
Origin Memory
|
Cutting Pause Paper Origin Memory
|
Display
|
Chinese and English Display Switch
|
|
Plotter Instruction
|
Compatible DM/PL,HP/GL
|
Output software
|
Artcut,signcut flexi CorelDRAW,CAD，Ai,etc
|
|
Cutting Consumable
|
|
Blade
|
Diameter 1.49mm the tungsten cutter
|
Drawing Refills
|
Atomic Drawing Refills
|
|
Voltage Consumption
|
|
Power supply
|
AC90~240V/50HZ-60HZ
|
Working Enviroment
|
+5-+35℃，Humidity: 30%-70%
|
|
Standby power consumption
|
<25W
|
Working Consumption
|
<100W
|
|
Volume/Weight
|
|
Package Size
|
1590×330×395mm
|
Gross weight
|
33KG
|
|
Applicable Industries
|
|
Advertisement; Glass sandblasting; Marble blasting; Die cutting samples; Article giftware making; Car/Wall stikcer; Paper Pattern; Printing; Logo and Signs.
|
|
Standard configuration：
|
|
Machine 1 set，1 set floor stand，1 serial port，1 pcs USB cable，1pcs CD，1pcs blade holder,3pcs blades，1pcs drawing pen.
|
